aCute A premium quality meshing software.


Implemented and licensed at the University of Florida, Gainesville
Partially funded by an NSF CAREER Award and an NSF Regular Grant
Contact: Alper Ungor, CISE Department, University of Florida, Gainesville, FL, 32611 ungoratcisedotufldotedu
Output Size Comparison
aCute creates smaller size triangulations. Tne number of Steiner points is almost the half of the number of Steiner points inserted by the previous Delaunay refinement methods.
aCute
Triangle


Smallest angle: 33, # Steiner points: 508,
# of triangles: 1564
Smallest angle: 33, # Steiner points: 1608,
# of triangles: 3731


Smallest angle: 30, # Steiner points: 1371,
# of triangles: 4012
Smallest angle: 30, # Steiner points: 3976,
# of triangles: 8836


Smallest angle: 30, # Steiner points: 2042,
# of triangles: 5319
Smallest angle: 30, # Steiner points: 7334,
# of triangles: 15723


Smallest angle: 30, # Steiner points: 279,
# of triangles: 1876
Smallest angle: 30, # Steiner points: 750,
# of triangles: 956


Smallest angle: 30, # Steiner points: 416,
# of triangles: 1715
Smallest angle: 30, # Steiner points: 813,
# of triangles: 2506


Smallest angle: 34, # Steiner points: 551,
# of triangles: 1621
Smallest angle: 34, # Steiner points: 2820,
# of triangles: 6135
Plot of average output size ratio of Triangle 1.4 and Triangle 1.6 with Algorithm 2 (our method) in
terms of the number of Steiner points vs. the constraint angle alpha for 40 data sets.
