• UF Sparse Matrix Collection
  • Matrix group: Pajek
  • Click here for a description of the Pajek group.
  • Click here for a list of all matrices
  • Click here for a list of all matrix groups


  • Matrix: Pajek/GD06_theory
  • Description: Pajek network: Graph Drawing contest 2006
  • download as a MATLAB mat-file, file size: 2 KB. Use UFget(1484) or UFget('Pajek/GD06_theory') in MATLAB.
  • download in Matrix Market format
  • download in Rutherford/Boeing format

    Pajek/GD06_theory

    Pajek/GD06_theory graph

    Matrix properties
    number of rows101
    number of columns101
    nonzeros380
    structural full rank?no
    structural rank20
    # of blocks from dmperm2
    # strongly connected comp.1
    explicit zero entries0
    nonzero pattern symmetrysymmetric
    numeric value symmetrysymmetric
    typebinary
    structuresymmetric
    Cholesky candidate?yes
    positive definite?no

    authorGraph Drawing Contest
    editorV. Batagelj
    date2006
    kindundirected graph
    2D/3D problem?no

    Notes:

    ------------------------------------------------------------------------------
    Pajek network converted to sparse adjacency matrix for inclusion in UF sparse
    matrix collection, Tim Davis.  For Pajek datasets, See V. Batagelj & A. Mrvar,
    http://vlado.fmf.uni-lj.si/pub/networks/data/.
    ------------------------------------------------------------------------------
     GD 2006 contest graph A: Theory
     http://gd2006.org/contest/details.php#theory
     graph in Pajek format
     transformed by Vladimir Batagelj, July 10, 2006


    Ordering statistics:AMD METIS
    nnz(chol(P*(A+A'+s*I)*P'))336 336
    Cholesky flop count1.3e+03 1.3e+03
    nnz(L+U), no partial pivoting571 571
    nnz(V) for QR, upper bound nnz(L) for LU721 721
    nnz(R) for QR, upper bound nnz(U) for LU3,401 3,401

    Maintained by Tim Davis, last updated 04-May-2008.
    Matrix pictures by cspy, a MATLAB function in the CSparse package.
    Matrix graphs by Yifan Hu, AT&T Labs Visualization Group.
