Matrix properties
number of rows	9,728
number of columns	9,728
nonzeros	725,144
structural full rank?	yes
structural rank	9,728
# of blocks from dmperm	1
# strongly connected comp.	1
entries not in dmperm blocks	0
explicit zero entries	0
nonzero pattern symmetry	symmetric
numeric value symmetry	symmetric
type	binary
structure	symmetric
Cholesky candidate?	yes
positive definite?	no

author	A. Andrianov
editor	T. Davis
date	2006
kind	optimization problem
2D/3D problem?	no

Ordering statistics:	AMD	METIS
nnz(chol(P*(A+A'+s*I)*P'))	12,293,576	9,726,138
Cholesky flop count	2.4e+10	1.5e+10
nnz(L+U), no partial pivoting	24,577,424	19,442,548
nnz(V) for QR, upper bound nnz(L) for LU	26,906,965	26,792,440
nnz(R) for QR, upper bound nnz(U) for LU	42,517,635	43,694,142
